miércoles, 25 de marzo de 2009

ALGUNOS CONSEJOS SOBRE LA ISS

ISS Repeater Tips
Miles Mann WF1F has published these tips on how to use the ISS 70cm to 2 metre FM repeater.
How to use the ISS Cross Band Repeater
By Miles Mann WF1F
MAREX-MG (Manned Amateur Radio Experiment, North American Division)
What is a Cross Band Repeater:
The Kenwood D700 on ISS supports several modes, including a mode called Cross Band Repeating. It allows signals on one band (70cm 437.800) to be received and simultaneously transmitted on another band (145.800 in this example). This combination is called Mode B in the satellite world.
When the radio is in this mode, Terrestrial stations can talk to other ham using most standard dual band FM transceivers, just like using a Mono-Band FM Repeater.
Since the Repeater is 220 miles altitude, it will have much greater range than a typical terrestrial repeater, up to 1400 miles in distance.
When is the Cross band Repeater turned on:
There is no set schedule. Most of it depends on access to the ISS crews. If there a slight gap in the crew schedule we can sometimes get the Repeater Mode turned on. It should be noted that the radio has not been modified for operations in Zero Gravity. All electronics run hotter inside the Space Station. The Cross Band repeater modes does put more thermal stress on the radio than other modes.
What Frequencies do I use:
The Cross Band repeater mode listens on 437.800 MHz FM, and will Transmit on 145.800 MHz FM. You will need to compensate for Doppler, especially on the Uplink side 437.800. On the 2-meter band 145.800, if you can not compensate for Doppler, do not worry about it. Most of the time you will be able to hear the down link signal fine. The Doppler on 145.800 is only 3.6 kHz maximum. Your stock FM receiver will still be able to hear ISS when it is 3khz off frequency.
The 437.800 uplink is a completely different story.
You will need to compensate for Doppler, every minute of the pass. If your radio has only a 5khz you will need to time your transmissions for when your Doppler error is less than 3khz different from you calculated uplink frequency. The closer your uplink frequency matches the receiver’s frequency on the repeater, the stronger you signal will be into the repeater.
For All mode Users. If you can pre save these split frequencies in to memory channels that will make life much easier during the short 10 minute ISS pass window.
For VFO users, this chart will help you sweep across the 70cm band and will help you stay on the correct uplink frequency.
Down RX Up TX
1 145.803 437.790
2 145.803 437.793
3 145.802 437.795
4 145.801 437.798
5 145.800 437.800
6 145.799 437.803
7 145.798 437.805
8 145.797 437.807
9 145.797 437.810
For users with Radio designed for 5 kHz channels steps, program in the following channel splits.
Down RX Up TX
1 145.800 437.790
2 145.800 437.795
3 145.800 437.800
4 145.800 437.805
5 145.800 437.810
How to I calculate Doppler:

Most satellite tracking programs will calculate the Doppler frequency error for a satellite. Here is an example from InstaTrack. I assigned the satellite ISS, the radio frequency of 437.800. The display reports will now show me the approximate Doppler error for a given time.
In this example, at 22:06 UTC time, the ISS will be in range of my location and the Doppler on 437.800 will be +10,240 Hz. In order for my signal to line up with the receiver, I need to transmit 10,240 Hz LOWER in frequency to compensate for Doppler + Positive shift in my frequency (Due to the 17,500 mile per hour speed of the Space Station).
So instead of transmitting on 437.800, I will transmit on 437.790.
Consejos del repetidor de la ISS.

Miles Mann, WF1F ha publicado estos consejos sobre cómo utilizar la ISS modo repetidor 70 cm a 2 metros FM.

Cómo usar la ISS Cruz Banda Repetidor
Por Miles Mann WF1F
MAREX-MG (Amateur Radio Experimento tripulados, División de América del Norte)

¿Qué es un repetidor de banda cruzada:

El Kenwood D700 de la ISS soporta varios modos, incluyendo un modo de repetición llamada Banda Crusada. Permite que las señales en una banda (70cm 437,800) que se ha recibido y transmitido simultáneamente en otra banda (145,800 en este ejemplo). Esta combinación se denomina Modo B en el mundo por satélite.

Cuando la radio esté en este modo, las estaciones terrestres pueden hablar a los demás utilizando la mayoría de los radioaficionados pueden utilizar un transmisores estandard de FM de doble banda, al igual que un mono usando la banda de FM-Repetidor.
Desde el repetidor es de 220 millas de altitud, tendrá mucho mayor alcance que un repetidor terrestre típico, de hasta 1400 millas de distancia.

Cuando el cross band se convirte en Repetidor:

No hay un orden fijo. La mayoría de los que depende el acceso a las tripulaciones de la ISS. Si existe una ligera diferencia en el calendario de la tripulación que a veces pueden ser el modo de repetidor activado. Cabe señalar que la radio no se ha modificado para las operaciones en gravedad cero. Todos los components electrónicos se calentarán más en el interior de la Estación Espacial. El repetidor de banda de Crusada pondra más estrés térmico en la radio que otros modos.

¿Qué frecuencias usar:

Para el repetidor de banda crusada en modo repetidor 437.800 MHz FM, y de transmisión de 145,800 MHz FM. Usted necesitará para compensar Doppler, sobre todo en el lado Uplink 437,800. 2-En la banda de 2m 145,800 , si no puede compensar Doppler, no te preocupes por él. La mayor parte del tiempo usted podrá escuchar la señal de enlace. El Doppler de 145,800 es sólo el 3,6 kHz máximo.
podrá escuchar la ISS cuando está fuera de 3kHz frecuencia.

Los 437,800 de enlace ascendente es totalmente diferente.
Usted necesitará para compensar Doppler, cada minuto de la tarjeta. Si tu radio tiene sólo un 5khz es necesario tiempo para su transmisión cuando el Doppler de error es inferior a 3kHz diferentes a usted calcula la frecuencia de enlace ascendente. Cuanto más cerca de su frecuencia de enlace ascendente coincide con la frecuencia del receptor en el repetidor, la señal más fuerte que será en el repetidor.

Modo para todos los usuarios. Si usted puede guardar estas pre división de frecuencias en los canales de memoria que hacen la vida mucho más fácil en los escasos 10 minutos de pasada de la ISS.

Para los usuarios con radios con VFO, esta tabla les ayudará a barrer toda la banda de 70 cm y le ayudará a permanecer en la correcta frecuencia de enlace ascendente.

Abajo RX Arriba TX
1 145,803 437,790
2 145,803 437,793
3 145,802 437,795
4 145,801 437,798
5 145,800 437,800
6 145,799 437,803
7 145,798 437,805
8 145,797 437,807
9 145,797 437,810


Para los usuarios con Radio diseñado para canales de pasos de 5 kHz, en el siguiente programa de canal se divide.
Abajo RX ArribaTX
1 145,800 437,790
2 145,800 437,795
3 145,800 437,800
4 145,800 437,805
5 145,800 437,810


¿Cómo calculo Doppler:

La mayoría de los programas de localización por satélite Doppler calcular la frecuencia de error de un satélite. Aquí hay un ejemplo de InstaTrack. Me asignó a la ISS por satélite, la radio frecuencia de 437,800. La pantalla ahora mostrará informes me Doppler aproximada de error para un determinado tiempo.

En este ejemplo, a las 22:06 hora UTC, la ISS será en el rango de mi ubicación y el Doppler en 437.800 serán 10.240 Hz. Con el fin de que mi señal a la línea con el receptor, que necesito para transmitir 10240 Hz de frecuencia inferior a la compensación de Doppler + cambio positivo en mi frecuencia (Debido a las 17,500 millas por hora la velocidad de la Estación Espacial).
Así que en vez de transmitir a 437,800, voy a transmitir a 437.790.

CHARLA CUERPO DE BOMBEROS SPM

CHARLA EN EL CUERPO DE BOMBEROS DE SAN PEDRO DE MACORIS

El Benemérito Cuerpo de Bomberos de la ciudad de San Pedro de Macorís fue cede para una charla dictada por el Radio Club Dominicano, Inc. A jóvenes aspirantes a Radioaficionados. Presentes; Bomberos, miembros de la Defensa Civil y la Cruz Roja El tema TU TAMBIEN PUEDES SER RADIOAFICIONADO fue dictada por los señores Ing. Vantroi Peña HI8VPB y Lic. Luís A. Mena HI8LAM el sábado 17 del mes Enero desde las 10:00 a.m. hasta las 02:00 p.m.

El Arq. General de Brigada Carlos Tomas Ramos, dio la bienvenida a los miembros del Radio Club Dominicano, Inc. A los cuales agradeció la charla al igual el Mayor Santana Director de la Academia de Bomberos y enlace con el Radio Club Dominicano.

Una nutrida delegación del Radio Club Dominicano, Inc. Compuesta por su presidente Sr. Hugo Ramón HI8VRS, y acompañado por los señores Víctor Báez HI8VB, Hugo Soñé HI8HS, Luís Beltrán HI8LIB, José Gil HI8JSG, David Flores HI8DBF, y Alan Sisa HI8ASU estuvieron entre los presentes en el recién inaugurado Cuartel General del Cuerpo de Bomberos de la ciudad de San Pedro de Macorís. En la Charla los disertantes hicieron principal hincapié sobre la función de los Radioaficionados en situaciones de Emergencias.

En la misma se encontraban presentes la Plana Mayor del Cuerpo de Bomberos. Después del Evento la comisión del Radio Club fue agasajada con un suculento Almuerzo.






jueves, 12 de marzo de 2009

GRACIAS A KB4YZ DAVID T JONES

Digital SSTV Nets & Frequencies
===============================
updated 3/10/2009

ANALOG SSTV Nets & Frequencies can be found here:
http://www.tima.com/~djones/net.txt)


* * * * * * * * *

70 cm (FM)

Friday 9 pm PT 441.950 MHz CA San Jose 100.0 PL

* * * * * * * * *

2 meters: (FM)

Every day 6:30 am ET 144.340 MHz IN W9NTP
Every day 1 pm ET 146.490 MHz TN/MS K8FA Art
Every day 6 pm ET 145.470 MHz IN Vevay Digital SSTV RPTR NG9Y Bob
Every day 7:30 pm UK 145.300 MHz UK CHESTERFIELD G4PBC John
Every day 7:30 pm ET 146.475 MHz IN Indianapolis (ECHOLINK AFTER 8 pm)
Every day 8 pm CT 145.100 MHz IL Peoria
Every day 8:30 pm ET 146.580 MHz VA SHACKLEFORDS - KE4EX GARY
Every day 9 pm ET 145.520 MHz TN BRISTOL W3YAE MARVIN
Every day 9 pm CT 147.240 MHz TX Waco RPTR W5NCD Larry Sun-Thr.
Every day 145.555 MHz TX Temple
Every day 145.650 MHz DOMINICAN REPUBLIC HI8LAM
Every day 10 pm CT 144.340 MHz IL Chicago (144.36)
Every day 145.625 MHz AUSTRALIA Gympie - SSTV Repeater uses EasyPal
Sunday 11 am ET 144.270 MHz ON ESPANOLA - VE3YYL LARRY
Sunday 8 pm CT 146.970 MHz IL Peoria RPTR 103.5 PL
Sunday 9:30 pm PT 146.790 MHz IN Anderson RPTR W9CSY Chuck
M/W/F 8 am ET 144.955 MHz IN Indianapolis N9AMR Tom
Monday 8 pm CT 145.550 MHz IL Chicago WA9MNF Ed
Tuesday 8 pm CT 145.550 MHz IL Chicago WA9MNF Ed
Wednesday 8 pm CT 145.500 MHz IL Springfield K7CZ Bill
Wednesday 10 pm ET 144.175 MHz MI GREAT LAKES DSSTV NET (USB)
Tu/Th 8 pm CT 144.150 MHz MS Coldwater K8FA Art
Thursday 8 pm 145.275 MHz UK Nottingham G4ROB Rob
Thursday 8 pm ET 146.490 MHz IN Bedford KB4YZ Dave
Thursday 8 pm CT 145.370 MHz IN Evansville Indiana KC9GIF Carlton
Friday 9 pm PT 147.300 MHz CA San Mateo 100.0 PL
Fri/Sat 8 pm CT 146.850 MHz MS Collierville WA4KOG RPTR
Saturday 7:30 pm ET 147.150 MHz NY Fulton (KW2M RPTR)

* * * * * * * * *

6 meters: (USB)
"MAGIC BAND"

Every day ? pm 50.680 MHz WI N0EDV
Every day 6:30 pm ET 51.250 MHz IN Central & Northern
Every day 8 pm CT 52.525 MHz IL Peoria
Every day 7:30 pm ET 50.325 MHz GA - KR4I Roger
Friday 7 pm CT 50.680 MHz MN Duluth - K0KP REX
M/W/F 8 pm CT 50.300 MHz MS Coldwater K8FA Art

* * * * * * * * *

10 meters: (USB)

Friday 7:30 pm ET 28.475 MHz PA New Oxford - N3IZ

* * * * * * * * *

15 meters: (USB)

Every day 21.370 MHz

* * * * * * * * *

17 meters: (USB)

Every day 13:00 UTC 18.1625 MHz TX Waco W5NCD Larry

* * * * * * * * *

20 meters: (USB)

Every day 14.233 MHz 20 Meter Band Digital SSTV Call Freq.
Every day 16:00 UTC 14.236 MHz also Digital Voice
Every day 14.240 MHz Australia/Europe
Every day 14.255 MHz
Every day 14.240 MHz
Weekdays 13:00 UTC 14.227 MHz TX W5NCD Larry/K4AWB Bob
Tuesday 18:00 UTC 14.236 MHz CO Denver W0LMD Robert

* * * * * * * * *

40 meters: (LSB)

Every day 10 am ET 7228 KHz Eastern US
Every day 8 pm ET 7173 KHz Eastern US - AA0OI
Every day 7183 KHz Australia
Every day all day ET 7173 KHz Eastern US - KB4YZ Dave
Sunday 10 am CT 7153 KHz TX W5FJS Wayne
Every day 7178 KHz US
Every day 7183 KHz US

* * * * * * * * *

75/80 meters: (LSB)

Every day 3733 KHz Europe
Every day 3736 KHz UK
Every day 10 am ET 3860 KHz Eastern US
Every day 8 am CT 3872 KHz Midwest US N9CQH Lex
Every day 7 am ET 3857 KHz Eastern US KC3AF Skip
Every day noon ET 3704 KHz Eastern Canada
Every day 7:30 pm ET 3720 KHz Eastern Canada
Every day 10 pm MT 3845 KHz CO + Western US - AA0OI
Every day 3637 KHz Australia
Weekdays 3:30 pm CT 3847 KHz TX W5FJS Wayne
Saturday 7 am CT 3855 KHz MN W0WVO Jerry
Sunday 8:30 am CT 3763 KHz IL WA9YZM
Sunday 3 pm AT 3724 KHz Eastern Canada
Every day 9 pm ET 3813 KHz US
Every night 9 pm ET 3713 KHz US
Every night 9 pm ET 3606 KHz US
Every night 9 pm ET 3927 KHz US

* * * * * * * * *

160 meters: (LSB)

Every day 7:30 pm ET 1898 KHz Eastern/Midwest US
Every day 5:00 pm ET 1950 KHz Eastern US N4RAN RANDY
Tu+Th 7:30 pm CT 1884 KHz TX W5FJS Wayne


Please notify Dave - KB4YZ of updates and corrections: djones@tima.com
Updated list is available at: http://www.tima.com/~djones/dignet.txt
